HP 14-r000ne And All r-000 Series

[bibinalappatt]

HP 14-r000ne

System Specifications:

CPU:Intel Core i5-4210U 1.7Ghz Haswell

GPU:NVIDIA GeForce 820M( Disabled)

RAM: 12GB (Installed 8GB to Second Port)

Ethernet:Realtek RTL 8106E

Sound: Realtek ALC282

WLAN:Ralink RT 3290 (Replaced With Broadcom BCM 94352 HMB

System Drive:WD Green 120GB



Bios Settings

Only Disabled Intel VT



Os Images

https://www.olarila.com/topic/6278-new-olarila-images/



Boot From Usb And Follow Installation



Post Installation

DSDT pathing Need For Battery Status and Brightness Key Mapping



Brightness Keys

Quote

into method label _Q11 replace_content

begin

// Brightness Down\n

Notify(\_SB.PCI0.LPCB.PS2K, 0x0405)\n

Notify(\_SB.PCI0.LPCB.PS2K, 0x0405)\n

end;

into method label _Q12 replace_content

begin

// Brightness Up\n

Notify(\_SB.PCI0.LPCB.PS2K, 0x0406)\n

Notify(\_SB.PCI0.LPCB.PS2K, 0x0406)\n

end;



Battery

Use RehabMan Laptop Patches

battery_HP-Folio-13-1010e



Finish Setup Happy Hackintoshing..

Special Credit @MaLd0n For the Awesome Installation Files and Tutorial



What are Working:

Sleep, Restart and Shutdown

Close Lid and Wake LID (Sleep and Wake via LID)

Audio Mic and Audio output

Touchpad

F12+13 Brightness Up + Down

F7 +8 Volume Up + Down

All USB ports



Clover Folder

CLOVER.zip



Video Demo
