Help with patching

hello

try this.. but dsdt is not god .. must find the right kext for u hardware.

[attachment=0]DSDT.aml.zip[/attachment]

read carefully and apply

http://Olarila.com/forum/viewtopic.php?f=27&t=1716

http://Olarila.com/forum/viewtopic.php?f=18&t=1703

http://Olarila.com/forum/viewtopic.php?f=18&t=2193

good hack

Extracted SSDT and enabled p and c States no KP so far thanks

boot list

Boot Graphics

Yes

EthernetBuiltIn

Yes

GenerateCStates

Yes

GeneratePStates

Yes

GraphicsEnabler

Yes

Kernel

mach_kernel

Kernel Flags

npci=0x2000

Legacy Logo

Yes

Theme

LoginToLion

Timeout

5

Should I remove sth?

artur-pt · February 20, 2013

hello

must try it, testing

if u gonna use ssdt

p and c-states=no

dropssdt=yes

and probably must patch the appleintecpupowermanagement.kext

hack is reading, googling and testing to find the right config to u hardware.

good hack

ruorbe · February 20, 2013

hello

must try it, testing

if u gonna use ssdt

p and c-states=no

dropssdt=yes

and probably must patch the appleintecpupowermanagement.kext

hack is reading, googling and testing to find the right config to u hardware.

good hack

Thanks u very much for your help I really appreciate it

I started from the very beginning this morning.

I found all the kexts but I need to patch sound for ALC1200

Also when I try to path AICPM only appear arch: x86_64 don't patch the wrmsrs

artur-pt · February 20, 2013

hello

the script patch for AICPM, u are not doing it well...

about u sound...

http://Olarila.com/forum/viewtopic.php?f=9&t=1933

good hack

ruorbe · February 20, 2013

hello

the script patch for AICPM, u are not doing it well...

about u sound...

http://Olarila.com/forum/viewtopic.php?f=9&t=1933

good hack

HELLO

What am I doing wrong?

Can you give me the AICPM patched out?

Thanks

Last login: Wed Feb 20 16:30:30 on console

Rubens-MacBook-Pro:~ Ruben$ cd ~/Downloads/AICPMPatch

Rubens-MacBook-Pro:AICPMPatch Ruben$ perl AICPMPatch.pl /System/Library/Extensions/AppleIntelCPUPowerManagement.kext/Contents/MacOS/AppleIntelCPUPowerManagement

/System/Library/Extensions/AppleIntelCPUPowerManagement.kext/Contents/MacOS/AppleIntelCPUPowerManagement

arch: x86_64

/System/Library/Extensions/AppleIntelCPUPowerManagement.kext/Contents/MacOS/AppleIntelCPUPowerManagement: Permission denied

Rubens-MacBook-Pro:AICPMPatch Ruben$ perl AICPMPatch.pl /System/Library/Extensions/AppleIntelCPUPowerManagement.kext/Contents/MacOS/AppleIntelCPUPowerManagement

artur-pt · February 20, 2013

hello

man where is sudo ????

to give root permissions ?

read carefully the guide...

perl AICPMPatch.pl /System/Library/Extensions/AppleIntelCPUPowerManagement.kext/Contents/MacOS/AppleIntelCPUPowerManagement

sudo perl AICPMPatch.pl /System/Library/Extensions/AppleIntelCPUPowerManagement.kext/Contents/MacOS/AppleIntelCPUPowerManagement --patch

good hack

ruorbe · February 20, 2013

hello

man where is sudo ????

to give root permissions ?

read carefully the guide...

perl AICPMPatch.pl /System/Library/Extensions/AppleIntelCPUPowerManagement.kext/Contents/MacOS/AppleIntelCPUPowerManagement

sudo perl AICPMPatch.pl /System/Library/Extensions/AppleIntelCPUPowerManagement.kext/Contents/MacOS/AppleIntelCPUPowerManagement --patch

good hack

Thanks mate

you're the best

ruorbe · February 23, 2013

hello

man where is sudo ????

to give root permissions ?

read carefully the guide...

perl AICPMPatch.pl /System/Library/Extensions/AppleIntelCPUPowerManagement.kext/Contents/MacOS/AppleIntelCPUPowerManagement

sudo perl AICPMPatch.pl /System/Library/Extensions/AppleIntelCPUPowerManagement.kext/Contents/MacOS/AppleIntelCPUPowerManagement --patch

good hack

Hi mate,

Thanks to you I got Mac OS X 10.8.2 perfectly running with native power management and sound.

AppleHDA's been patched as well as the SmartBattery although sound doesn't work after wake and battery displays 0% can you help me out with the DSDT edition?

Thanks again.

ruorbe · February 23, 2013

hello

DSDT

Send me Ruben’s MacBook Pro.zip

artur-pt · February 23, 2013

hello

about sleep, not equal to all hack....

must search the right way to u note... google it and read about...

about battery only know 2 ways

dsdt and a case is a case , not a generic patch..

read all about here

http://www.insanelymac.com/forum/topic/264597-hp-dvx-acpi-3x4x-battery-driver-106107/

or the easy way

http://www.osx86.net/downloads.php?do=file&id=1384

good hack

ruorbe · February 23, 2013

hello

about sleep, not equal to all hack....

must search the right way to u note... google it and read about...

about battery only know 2 ways

dsdt and a case is a case , not a generic patch..

read all about here

http://www.insanelymac.com/forum/topic/264597-hp-dvx-acpi-3x4x-battery-driver-106107/

or the easy way

http://www.osx86.net/downloads.php?do=file&id=1384

good hack

Thanks Dude I'll check the old-fashioned way

Cheers

ruorbe · February 24, 2013

Thanks Dude I'll check the old-fashioned way

Cheers

Hi there.

Patched IOAudiofamily fixed no sound after sleep and Patched AppleACIPlatform fixed battery info. The only thing about that is Fn keys don't work, the rest yes, I dont know why.

Do I need IOPCIFamily, lspcidrv and Patched_10.7_AppleRTC in my E/E folder?

and may you give me a hint about SDcard and Bluetooth

Thanks

ruorbe · February 25, 2013

I've found Sth to fix the SDreader but I've noticed that only 1USB is working, I've tried USB fix, anything did though.

Can you check it out?

Thanks.

Send me Ruben’s MacBook Pro.zip

artur-pt · February 25, 2013

hello

if u have usb3, must find the right kext for u usb3 chipset

good hack

ruorbe · February 25, 2013

hello

if u have usb3, must find the right kext for u usb3 chipset

good hack

That's odd it just has 3 usb2.0 and I've opened it up and there well-conected.

ruorbe · February 28, 2013

hello

if u have usb3, must find the right kext for u usb3 chipset

good hack

Hi Artur I cant find any solution about the USB ports missing also I'd like to ask you how to enable HDMI audio if you dont mind...

Thanks.

artur-pt · February 28, 2013

hello

in mac os x audio only 2 solutions

voodoohda / applehda

must use one or another....

http://Olarila.com/forum/viewtopic.php?f=18&t=454

http://Olarila.com/forum/viewtopic.php?f=18&t=2676

http://Olarila.com/forum/viewtopic.php?f=9&t=1933

no easy way...

good hack

ruorbe · March 1, 2013

hello

in mac os x audio only 2 solutions

voodoohda / applehda

must use one or another....

http://Olarila.com/forum/viewtopic.php?f=18&t=454

http://Olarila.com/forum/viewtopic.php?f=18&t=2676

http://Olarila.com/forum/viewtopic.php?f=9&t=1933

no easy way...

good hack

Hello.

Really hard dude, I've got it , though.

If u could give me a hand about the USB ports I'd really appreciated. It's the only thing left for a 100%vanilla hack.

Thanksa lot

ruorbe · March 1, 2013

Hello.

Really hard dude, I've got it , though.

If u could give me a hand about the USB ports I'd really appreciated. It's the only thing left for a 100%vanilla hack.

Thanksa lot

I found that

Ruben$ sudo kextcache -prelinked-kernel

Password:

Can't record kext in identifier lookup dictionary; no identifier.

Kernel file /mach_kernel does not contain requested arch: i386

BJUSBLoad.kext - no dependency found for com.apple.kernel.libkern.

BJUSBLoad.kext is missing dependencies (including anyway; dependencies may be available from elsewhere)

BJUSBLoad.kext - no dependency found for com.apple.kernel.libkern.

artur-pt · March 1, 2013

hello

something is wrong with u system kext...

that's why u boot problems...

Can't record kext in identifier lookup dictionary; no identifier.

the other msg no problem

u kernel cache have problems...

good hack

ruorbe · March 1, 2013

hello

something is wrong with u system kext...

that's why u boot problems...

Can't record kext in identifier lookup dictionary; no identifier.

Can't record kext in identifier lookup dictionary; no identifier.

Can't record kext in identifier lookup dictionary; no identifier.

Can't record kext in identifier lookup dictionary; no identifier.

the other msg no problem

u kernel cache have problems...

good hack

Hello I can't see anything

PMAP: PCID enabled

Darwin Kernel Version 12.2.0: Sat Aug 25 00:48:52 PDT 2012; root:xnu-2050.18.24~1/RELEASE_X86_64

vm_page_bootstrap: 1894816 free pages and 54880 wired pages

kext submap [0xffffff7f80741000 - 0xffffff8000000000], kernel text [0xffffff8000200000 - 0xffffff8000741000]

zone leak detection enabled

standard timeslicing quantum is 10000 us

standard background quantum is 2500 us

mig_table_max_displ = 74

TSC Deadline Timer supported and enabled

Refusing new kext com.apple.driver.AppleRTC, v1.5: already have prelinked v1111.0.

corecrypto kext started!

Running kernel space in FIPS MODE

Plist hmac value is 735d392b68241ef173d81097b1c8ce9ba283521626d1c973ac376838c466757d

Computed hmac value is 735d392b68241ef173d81097b1c8ce9ba283521626d1c973ac376838c466757d

corecrypto.kext FIPS integrity POST test passed!

corecrypto.kext FIPS AES CBC POST test passed!

corecrypto.kext FIPS TDES CBC POST test passed!

corecrypto.kext FIPS AES ECB AESNI POST test passed!

corecrypto.kext FIPS AES XTS AESNI POST test passed!

corecrypto.kext FIPS SHA POST test passed!

corecrypto.kext FIPS HMAC POST test passed!

corecrypto.kext FIPS ECDSA POST test passed!

corecrypto.kext FIPS DRBG POST test passed!

corecrypto.kext FIPS POST passed!

AppleACPICPU: ProcessorId=1 LocalApicId=0 Enabled

AppleACPICPU: ProcessorId=2 LocalApicId=2 Enabled

AppleACPICPU: ProcessorId=3 LocalApicId=1 Enabled

AppleACPICPU: ProcessorId=4 LocalApicId=3 Enabled

AppleACPICPU: ProcessorId=5 LocalApicId=4 Disabled

AppleACPICPU: ProcessorId=6 LocalApicId=5 Disabled

AppleACPICPU: ProcessorId=7 LocalApicId=6 Disabled

AppleACPICPU: ProcessorId=8 LocalApicId=7 Disabled

AppleACPICPU: ProcessorId=9 LocalApicId=8 Disabled

AppleACPICPU: ProcessorId=10 LocalApicId=9 Disabled

AppleACPICPU: ProcessorId=11 LocalApicId=10 Disabled

AppleACPICPU: ProcessorId=12 LocalApicId=11 Disabled

AppleACPICPU: ProcessorId=13 LocalApicId=12 Disabled

AppleACPICPU: ProcessorId=14 LocalApicId=13 Disabled

AppleACPICPU: ProcessorId=15 LocalApicId=14 Disabled

AppleACPICPU: ProcessorId=16 LocalApicId=15 Disabled

calling mpo_policy_init for TMSafetyNet

Security policy loaded: Safety net for Time Machine (TMSafetyNet)

calling mpo_policy_init for Sandbox

Security policy loaded: Seatbelt sandbox policy (Sandbox)

calling mpo_policy_init for Quarantine

Security policy loaded: Quarantine policy (Quarantine)

MAC Framework successfully initialized

using 16384 buffer headers and 10240 cluster IO buffer headers

IOAPIC: Version 0x20 Vectors 64:87

ACPI: System State [s0 S3 S4 S5] (S3)

RTC: Only single RAM bank (128 bytes)

AppleIntelCPUPowerManagement: Turbo Ratios 0046

AppleIntelCPUPowerManagement: (built 23:03:24 Jun 24 2012) initialization complete

AppleACPIBatteryManager Loading...

AppleACPIBatteryDevice loading...

PFM64 (36 cpu) 0xf80000000, 0x80000000

[ PCI configuration begin ]

mbinit: done [64 MB total pool size, (42/21) split]

Pthread support ABORTS when sync kernel primitives misused

console relocated to 0xf80000000

PCI configuration changed (bridge=5 device=1 cardbus=0)

[ PCI configuration end, bridges 4 devices 11 ]

rooting via boot-uuid from /chosen: 3F08E8F3-FA17-3736-A75C-EA81D58DAA64

Waiting on IOProviderClassIOResourcesIOResourceMatchboot-uuid-media

com.apple.AppleFSCompressionTypeZlib kmod start

com.apple.AppleFSCompressionTypeDataless kmod start

com.apple.AppleFSCompressionTypeZlib load succeeded

com.apple.AppleFSCompressionTypeDataless load succeeded

AppleIntelCPUPowerManagementClient: ready

Got boot device = IOService:/AppleACPIPlatformExpert/PCI0@0/AppleACPIPCI/IDE0@1F,2/AppleIntelPchSeriesAHCI/CHN0@0/IOAHCIDevice@0/AppleAHCIDiskDriver/IOAHCIBlockStorageDevice/IOBlockStorageDriver/WDC WD3200BPVT-80ZEST0 Media/IOGUIDPartitionScheme/Hard Drive@2

BSD root: disk0s2, major 1, minor 3

Kernel is LP64

ath_get_caps[4038] rx chainmask mismatch actual 1 sc_chainmak 0

0.718043: ath_get_caps[4013] tx chainmask mismatch actual 1 sc_chainmak 0

0.722498: Atheros: mac 192.2 phy 14.0 radio 12.0

0.722510: Use hw queue 0 for WME_AC_BE traffic

0.722518: Use hw queue 1 for WME_AC_BK traffic

0.722525: Use hw queue 2 for WME_AC_VI traffic

0.722532: Use hw queue 3 for WME_AC_VO traffic

0.722540: Use hw queue 8 for CAB traffic

0.722546: Use hw queue 9 for beacons

0.722692: wlan_vap_create : enter. devhandle=0xc487e658, opmode=IEEE80211_M_STA, flags=0x1

0.722749: wlan_vap_create : exit. devhandle=0xc487e658, opmode=IEEE80211_M_STA, flags=0x1.

0.722844: start[1012] sc->sc_inuse_cnt is at offset: 203c, sizeof(_sc->sc_ic) is 25f0

Waiting for DSMOS...

macx_swapon SUCCESS

AirPort_AtherosNewma40: Ethernet address e0:b9:a5:ae:40:fd

IO80211Controller::dataLinkLayerAttachComplete(): adding AppleEFINVRAM notification

IO80211Interface::efiNVRAMPublished():

23.081407: ATHR: unknown locale: 60

AtherosNewma40P2PInterface::init name role 1 this 0xffffff8011a9e000

AtherosNewma40P2PInterface::init() role 1

AirPort: Link Down on en0. Reason 1 (Unspecified).

en0::IO80211Interface::postMessage bssid changed

23.721866: ATHR: unknown locale: 60

Welcome to ControllerMate v4.6 (64-bit)

Elan: Detecting the touchpad

Previous Shutdown Cause: 3

DSMOS has arrived

Elan: Touchpad found, Assuming hardware version 3 (with firmware version 0x450f01)

No interval found for . Using 8000000

Sound assertion in AppleHDAController at line 1294

Elan: Placing the Touchpad into Absolute mode

Elan: Successfully placed touchpad into Absolute mode

Transcript Offline - Buffer Pool Allocate [181000] failed

Elan: MouseInformation { 0x20, 0x03, 0x64 }

Elan: Enabling the touchpad

24.424778: setWOW_PARAMETERS:wowevents = 2(1)

33.557112: setDISASSOC from ATH_INTERFACE_CLASS disconnectVap

33.557142: switchVap from 1 to 1

33.572426: performCountryCodeOperation: Not connected, scan in progress[0]

33.578619: ATHR: unknown locale: 60

33.594316: ATHR: unknown locale: 60

33.594989: ATHR: unknown locale: 60

en0: 802.11d country code set to 'GB '.

33.712248: ATHR: unknown locale: 60

en0: Supported channels 1 2 3 4 5 6 7 8 9 10 11 12 13

en0: BSSID changed to 84:c9:b2:ba:23:98

en0::IO80211Interface::postMessage bssid changed

AirPort: Link Up on en0

en0: BSSID changed to 84:c9:b2:ba:23:98

en0::IO80211Interface::postMessage bssid changed

34.424144: apple80211Request[10292] Unsupported ioctl 111

AirPort: RSN handshake complete on en0

42.779028: ATHR: unknown locale: 60

43.399173: ATHR: unknown locale: 60

43.415192: ATHR: unknown locale: 60

nspace-handler-set-snapshot-time: 1362153214

NoEjectDelay --Info-- init 4.1.0-10.8

NoEjectDelay --Info-- start

NoEjectDelay --Info-- device: Keyboard (ApplePS2Keyboard)

47.084276: ATHR: unknown locale: 60

52.302734: ATHR: unknown locale: 60

No interval found for . Using 8000000

NoEjectDelay --Info-- device: ControllerMate (Virtual Keyboard)

NoEjectDelay --Info-- device: ControllerMate (Virtual Consumer)

NoEjectDelay --Info-- device: ControllerMate (Virtual Keyboard)

EAPD: Sending Command

EAPD: Enabled Successfully

considerRebuildOfPrelinkedKernel org.pqrs.driver.NoEjectDelay triggered rebuild

Sandbox: sandboxd(263) deny mach-lookup com.apple.coresymbolicationd

Rubens-MacBook-Pro:~ Ruben$

artur-pt · March 1, 2013

hello

that is the problem

No interval found for . Using 8000000

NoEjectDelay --Info-- device: ControllerMate (Virtual Keyboard)

NoEjectDelay --Info-- device: ControllerMate (Virtual Consumer)

NoEjectDelay --Info-- device: ControllerMate (Virtual Keyboard)

EAPD: Sending Command

EAPD: Enabled Successfully

considerRebuildOfPrelinkedKernel org.pqrs.driver.NoEjectDelay triggered rebuild

Sandbox: sandboxd(263) deny mach-lookup com.apple.coresymbolicationd

considerRebuildOfPrelinkedKernel org.pqrs.driver.NoEjectDelay triggered rebuild

good hack

ruorbe · March 1, 2013

hello

that is the problem

No interval found for . Using 8000000

No interval found for . Using 8000000

NoEjectDelay --Info-- device: ControllerMate (Virtual Keyboard)

NoEjectDelay --Info-- device: ControllerMate (Virtual Keyboard)

NoEjectDelay --Info-- device: ControllerMate (Virtual Consumer)

NoEjectDelay --Info-- device: ControllerMate (Virtual Keyboard)

EAPD: Sending Command

EAPD: Enabled Successfully

considerRebuildOfPrelinkedKernel org.pqrs.driver.NoEjectDelay triggered rebuild

Sandbox: sandboxd(263) deny mach-lookup com.apple.coresymbolicationd

considerRebuildOfPrelinkedKernel org.pqrs.driver.NoEjectDelay triggered rebuild

good hack

I dont think thats the root of my non-working Usb ports' issue.

My Usb ports didnt work before I set volume and eject controls through virtual-mate

Sign In

Help with patching

Recommended Posts

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Join the conversation

Hackintosh Tutorials

Hackintosh Tutorials

Support Olarila by making a donation
