Olarila HackBeast Z390 M Gaming - Full DSDT patches

[astroboyvn88 0]

Hi MaLd0n,

Please see the attachment. Everything seems to work just fine except it always reboot when I shut it down - very annoying when I have to force shutdown every time. Also, the 3.5 mm audio input jack seems doesn't work although bluetooth audio works just fine

Thanks

Send me Quocs-iMac.zip

[MaLd0n 1,001,037]

[ref]astroboyvn88[/ref], Arquivo Comprimido.zip

[astroboyvn88 0]

MaLd0n, it works flawlessly. Thanks!!!

The headphone jack doesn't work although audio Bluetooth works just fine. Will there be also a way to fix it?

[MaLd0n 1,001,037]

[ref]astroboyvn88[/ref], audio u need test other layout-id

https://Olarila.com/forum/viewtopic.php?f=28&t=9788

[astroboyvn88 0]

Thanks MaLd0n, I'll check it out. You rock!

[astroboyvn88 0]

MaLd0n,

I know the reason why my audio jack doesn't work. If I use your EFI folder provided, audio works just fine. However, when using hackintool to patch so I can use internal graphics, the sound somehow got disabled... Any recommendations MaLd0n?

Thank you

[MaLd0n 1,001,037]

[ref]astroboyvn88[/ref], post ur efi here

[astroboyvn88 0]

here MaLd0n,

Thanks!!!

EFI.zip

[MaLd0n 1,001,037]

[ref]astroboyvn88[/ref], use Olarila clover folder with my dsdt and ssdt 06

https://Olarila.com/forum/viewtopic.php?f=28&t=8222

[locus 0]

Hi

Currently, I have a strange behaviour with my z390 m gaming (F7) build.

This just happened suddenly after tinkering with my clover config.

Right after shutdown or sometimes after a crash after a long sleep, I get a "couldn't allocate runtime area" error that doesn't go away unless I re-flash the bios. Then I can boot again (usually only one time and then the same error shows up again).

I also checked memmap and I should have enough available space at 0x0000000000100000.

Anyone has an idea what the issue could be?

At the moment I use the 300 series clover config from your site here, but without a custom sdst or ssdt.

Thanks in advance for any tips..

[MaLd0n 1,001,037]

[ref]locus[/ref], post one full dump

--Run_Me

RunMe.app

[locus 0]

Hi MaLd0n,

Here you go.

Send me macstation.zip

[MaLd0n 1,001,037]

[ref]locus[/ref], check if work

EFI.zip

[locus 0]

Hi MaLd0n, after another BIOS flash boot-up looks good. Didn't spot any ACPI errors

The only thing is, with your EFI my Broadcom BCM94360CD PCIe Adapter doesn't work anymore.

Is this something that needs to be added back the ssdt?

Note to myself, I really need to check out how dsdt/ssdt's work

[MaLd0n 1,001,037]

[ref]locus[/ref], AirportBrcmFixup.kext.zip

[locus 0]

MaLd0n,

thanks for the tip, but you already included AirportBrcmFixup.kext in your EFI.zip.

I have added this kext but still the Broadcom card doesn't work with it.

Btw, if I boot without your DSDT then the card works natively.

Another strange thing is, that I still need to re-flash the BIOS (or clear the CMOS) after almost every shutdown or I still get the "couldn't allocate runtime area" error.

But I assume that are two different, unrelated issues.

Have you ever had this problem as well?

But hey, thanks alot so for for helping me out. Its really appreciated!

[MaLd0n 1,001,037]

[ref]locus[/ref], if u update bios need edited again

[locus 0]

Looks like to following change made Bluetooth work again. Was probably just a typo



--- a/patched MaLd0n for me/SSDT-6-A M I.dsl
+++ b/patched MaLd0n for me/SSDT-6-A M I.dsl
@@ -1448,7 +1448,7 @@ DefinitionBlock ("", "SSDT", 2, "ALASKA", "A M I", 0x00000000)
                {
                    If (LEqual (And (UMAP, 0x0200), 0x0200))
                    {
-                        Return (MALD (Zero))
+                        Return (MALD (One))
                    }
                    Else
                    {



Added in 5 minutes 49 seconds:

[ref]locus[/ref], if u update bios need edited again



Yes, I have read that in one of your previous posts.

I am on the latest version F7 all the time. I don't plan to upgrade it anymore, unless there is an important reason for it.

[astroboyvn88 0]

hi MaLd0n,

I just upgraded to Catalina, everything works fine, the only thing is the DSDT you gave me for proper shutdown doesn't work anymore, it gives me bootloop when copying to ACPI/patched folder.

Attached is the zip file you sent me previously

Arquivo Comprimido.zip

[MaLd0n 1,001,037]

[ref]astroboyvn88[/ref], the file is same, idk what cause it

[astroboyvn88 0]

Hi MaLd0n

I know why now, I normally stick my card in the pci 1 slot. However, I swapped it to the pci 2 slot since my new rx580 card is quite big and the fan hit my wifi card, so I had to move it to the pci 2 slot . Switching it back to the 1st slot solves the problem but then it also means I have to remove my wifi card

How do I modify the dsdt, ssdt you sent me so it works with pci slot 2?

Thanksss

[MaLd0n 1,001,037]

[ref]astroboyvn88[/ref], work in both slots, but ever use in first

[ronny973 0]

hey im new to the hackintosh world. I want to do this build bc i already chose this motherboard. Will this guide work if i use a 9900 or i7-9700k instead of the 9900k?

[MaLd0n 1,001,037]

[ref]ronny973[/ref], yes, just avoid processor with F, processors without igpu intel quick sync don't work, not good

[telepati 3]

[ref]MaLd0n[/ref], I update BIOS to F7 when installing Catalina should I need new DSDT or old DSDT enough?
